Depth Capacity

HQ Rod size : 150 m

Power Pack

D1505 Diesel Engine Vertical

Max. Power 31 kW @3000 rpm

Hydraulic System

Hydraulic Pump Double Series 3 and Series 2 By Italy

Max. Pressure 210 Bar

Rotary Drill Head

Top Drive Gearbox Single Line Rotation Motor 4000 Series

Type Disc Valve Eaton

Drill Mast and Feed System

Drilling Angle : 90 Degree

Pull Down Force : 7418 Kg @200 Bar

Pull Up Force : 11335 Kg @200 Bar

Feed Stroke : 1.8 m

Rod Pull: 6 m

Hydraulic Main Winch Assy

Rotation Motor 4000 Series (625 cc) Eaton Type Disc

Hydraulic Main Wireline Assy

Rotation Motor 2000 Series (395 cc) Eaton Type Disc

Hydraulic Control Panel

P80-3 Sectional Directional Control Valves

P80-3 Monoblock Directional Control Valves
